TPS2110PWG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - OR Controllers, Ideal Diodes
Description ACTIVE (Last Updated: 1week ago) Tube Handheld/Mobile Devices e4 ideal diode 750mA 0.65mm 2.8V~5.5V 3ms
PDF
/
Buying Options
Total Price: USD $10.73
Unit Price: USD $10.72835
≥1 USD $10.72835
≥10 USD $8.8027
≥100 USD $8.52815
≥500 USD $8.25265
≥1000 USD $7.97715
Inventory: 1538
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 8
Weight 39.008944mg

Technical

Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Source Selector Switch
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Handheld/Mobile Devices
Subcategory Power Management Circuits
Voltage - Supply 2.8V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.8V
Terminal Pitch 0.65mm
Base Part Number TPS2110
Pin Count 8
Number of Outputs 1
Max Output Current 750mA
Operating Supply Voltage 5.5V
Number of Channels 2
Output Current 750mA
Adjustable Threshold YES
Turn On Delay Time 500 μs
Current - Supply 55μA
Min Input Voltage 2.8V
FET Type N-Channel
Number of Inputs 2
Max Input Voltage 5.5V
Supply Current-Max (Isup) 0.09mA
Nominal Input Voltage 5.5V
Ratio - Input:Output 2:1
Internal Switch(s) Yes
Current - Output 2 750mA
Delay Time - OFF 3ms

Dimensions

Height 1.2mm
Length 3mm
Width 4.4mm
Thickness 1mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
