TPS2104D
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - OR Controllers, Ideal Diodes
Description
ROHS3Compliant Surface Mount Source Selector Switch GULL WING OR Controller Source Selector Switch -40C~85C 2.7V~5.5V 1.27mm 500mA 100mA
PDF
/
Buying Options
Total Price: USD $8.2
Unit Price: USD $8.198745
≥1 USD $8.198745
≥10 USD $7.734665
≥100 USD $7.296855
≥500 USD $6.883824
≥1000 USD $6.494175
Inventory: 3915
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
Type Source Selector Switch
Terminal Finish NICKEL PALLADIUM GOLD
Applications Handheld/Mobile Devices
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 220; 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code R-PDSO-G8
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Current - Output (Max) 500mA 100mA
Current - Supply 18μA
FET Type N and P-Channel
Ratio - Input:Output 2:1
Internal Switch(s) Yes
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
