LTC4420IDD#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 12-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - OR Controllers, Ideal Diodes
Description
PRODUCTION (Last Updated: 2weeks ago) Tape & Reel (TR) Battery Backup LTC4420 ideal diode 1.6A 0.45mm 1.8V~18V -40C~85C
PDF
/
Inventory: 5681
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case 12-WFDFN Exposed Pad
Surface Mount YES
Number of Pins 12
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2016
Series PowerPath?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
Type Source Selector Switch
Applications Battery Backup
Additional Feature SEATED HT-CALCULATED
Technology CMOS
Voltage - Supply 1.8V~18V
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3.6V
Terminal Pitch 0.45mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LTC4420
Pin Count 12
Supply Voltage-Max (Vsup) 18V
Supply Voltage-Min (Vsup) 1.8V
Number of Channels 2
Current - Output (Max) 1.6A
Adjustable Threshold YES
Current - Supply 3.6μA
FET Type N-Channel
Supply Current-Max (Isup) 0.0063mA
Ratio - Input:Output 2:1
Internal Switch(s) Yes
Dimensions
Height Seated (Max) 0.8mm
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
