VNH5019A-E
RoHS
RoHS compliant
RoHS compliantPackage 30-PowerSOP (0.630, 16.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
Power MOSFET Tube VNH5019 Automotive motor driver 41V 50A 16.1mm -40C~150C TJ
PDF
/
Buying Options
Total Price: USD $13.42
Unit Price: USD $13.42445
≥1 USD $13.42445
≥10 USD $11.01525
≥100 USD $10.6704
≥500 USD $10.3265
≥1000 USD $9.9826
Inventory: 1514
Minimum: 1
-
+
Technical Details
Technical
Voltage - Supply 5.5V~24V
Technology Power MOSFET
Applications Automotive
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 30
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series ECOPACK?, VIPower?
Packaging Tube
Operating Temperature -40°C~150°C TJ
Motor Type - AC, DC Brushed DC
Output Current Flow Direction SOURCE SINK
Motor Type Brushed
Built-in Protections TRANSIENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Switching Frequency 20kHz
Output Peak Current Limit-Nom 50A
Voltage - Load 5.5V~24V
Max Collector Current 30A
Collector Emitter Voltage (VCEO) 41V
Output Configuration Half Bridge (2)
Nominal Supply Current 8mA
Interface Parallel, PWM
Number of Outputs 1
Function Driver - Fully Integrated, Control and Power Stage
Base Part Number VNH5019
Time@Peak Reflow Temperature-Max (s) 3
Supply Voltage 13V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Physical
Number of Pins 30
Package / Case 30-PowerSOP (0.630, 16.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 42 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 16.1mm
Length 17.3mm
Height 2.35mm
