L6258EXTR
RoHS
RoHS compliant
RoHS compliantPackage PowerSO-36 Exposed Bottom Pad
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
DMOS Tape & Reel (TR) L6258 General Purpose motor driver 40V 1.2A 11mm 150C TJ
PDF
/
Buying Options
Total Price: USD $70.49
Unit Price: USD $70.49285
≥1 USD $70.49285
≥10 USD $68.2898
≥100 USD $66.0877
≥500 USD $63.88465
≥1000 USD $57.2755
Inventory: 1257
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case PowerSO-36 Exposed Bottom Pad
Number of Pins 36
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications General Purpose
HTS Code 8542.39.00.01
Subcategory Motion Control Electronics
Technology DMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.65mm
Base Part Number L6258
Function Driver - Fully Integrated, Control and Power Stage
Operating Supply Voltage 40V
Supply Voltage-Max (Vsup) 5.25V
Supply Voltage-Min (Vsup) 4.75V
Interface Parallel
Analog IC - Other Type STEPPER MOTOR CONTROLLER
Output Configuration Half Bridge (4)
Current - Output 1.2A
Logic Function AND
Voltage - Load 12V~40V
Motor Type - AC, DC Brushed DC
Motor Type - Stepper Bipolar
Step Resolution 1, 1/2, 1/4, 1/8, 1/16
Dimensions
Height Seated (Max) 3.6mm
Length 15.9mm
Width 11mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
