LV8804V-TLM-H
RoHS
RoHS compliant
RoHS compliantPackage 36-LSOP (0.220, 5.60mm Width)
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
BRUSH DC MOTOR CONTROLLER
PDF
/
Buying Options
Total Price: USD $9.95
Unit Price: USD $9.9465
≥1 USD $9.9465
≥10 USD $8.16145
≥100 USD $7.9059
≥500 USD $7.6513
≥1000 USD $7.39575
Inventory: 1143
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 36-LSOP (0.220, 5.60mm Width)
Supplier Device Package 36-SSOPJ
Technical
Operating Temperature -30°C~95°C TA
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Applications Fan Motor Driver
Technology Bi-CMOS
Voltage - Supply 6V~15V
Function Driver - Fully Integrated, Control and Power Stage
Interface PWM
Output Configuration Half Bridge (3)
Current - Output 1.2A
Voltage - Load 6V~15V
Motor Type - AC, DC Brushless DC (BLDC)
Compliance
RoHS Status ROHS3 Compliant
