STK681-332-E
RoHS
RoHS compliant
RoHS compliantPackage 19-SSIP Formed Leads
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
Power MOSFET Bulk STK681 General Purpose motor driver 42V 6.1A 4.5mm -20C~105C TC
PDF
/
Buying Options
Total Price: USD $11.63
Unit Price: USD $11.626099
≥1 USD $11.626099
≥10 USD $10.968014
≥100 USD $10.34718
≥500 USD $9.761496
≥1000 USD $9.208951
Inventory: 1395
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.5mm
Length 24.2mm
Height 14.4mm
Technical
Motor Type - AC, DC Brushed DC
Switching Frequency 46kHz
Voltage - Load 10V~42V
Max Collector Current 6.1A
Collector Emitter Voltage (VCEO) 42V
Supply Current-Max (Isup) 9mA
Power Dissipation 2.8W
Output Configuration Half Bridge (2)
Nominal Supply Current 6mA
Analog IC - Other Type BRUSH DC MOTOR CONTROLLER
Interface Parallel
Supply Voltage-Min (Vsup) 4.75V
Power Supplies 524V
Operating Supply Voltage 5.25V
Max Output Current 12A
Output Voltage 42V
Number of Outputs 1
Function Driver - Fully Integrated, Control and Power Stage
Base Part Number STK681
Supply Voltage 5V
Terminal Position ZIG-ZAG
Voltage - Supply 4.75V~5.25V
Technology Power MOSFET
Subcategory Motion Control Electronics
Applications General Purpose
Terminal Finish Tin/Nickel (Sn/Ni)
Number of Terminations 19
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Published 2011
Packaging Bulk
Operating Temperature -20°C~105°C TC
Physical
Number of Pins 19
Package / Case 19-SSIP Formed Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 13 Weeks
Alternative Model
