LV8075LP-TE-L-E
RoHS
/
Package 16-WFQFN
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
RoHS Compliant Lead Free QUAD Brushed (Motor Type - AC, DC) Motor Driver -30C~85C TA 2.6mm 500mA 5V
PDF
/
Buying Options
Total Price: USD $1.96
Unit Price: USD $1.9624
≥1 USD $1.9624
≥10 USD $1.75912
≥100 USD $1.65968
Inventory: 111
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-WFQFN
Number of Pins 16
Technical
Operating Temperature -30°C~85°C TA
Packaging Cut Tape (CT)
Published 2010
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Applications General Purpose
Subcategory Motion Control Electronics
Technology Bi-CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position QUAD
Supply Voltage 3V
Terminal Pitch 0.5mm
Base Part Number LV8075
Function Driver - Fully Integrated, Control and Power Stage
Number of Outputs 2
Max Output Current 500mA
Power Supplies 3V
Interface Parallel
Operating Supply Current 1μA
Output Configuration Half Bridge (2)
Supply Current-Max (Isup) 1mA
Collector Emitter Voltage (VCEO) 5V
Max Collector Current 500mA
Voltage - Load 2.5V~5.5V
Motor Type Brushed
Motor Type - AC, DC Brushed DC
Dimensions
Height 800μm
Length 2.6mm
Width 2.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
