TC649BEOATR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
ROHS3Compliant Lead Free DUAL GULL WING (Motor Type - AC, DC) Motor Driver -40C~85C TA 4.9mm 400muA 3.3/5V
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.336532
≥1 USD $1.336532
≥200 USD $0.517283
≥500 USD $0.498902
≥1000 USD $0.491025
Inventory: 1343
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2003
Series FanSense?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications Fan Controller
Subcategory Motion Control Electronics
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TC649
Function Controller - Speed
Number of Outputs 1
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.3/5V
Supply Voltage-Min (Vsup) 3V
Interface Parallel
Analog IC - Other Type BRUSHLESS DC MOTOR CONTROLLER
Nominal Supply Current 400μA
Output Configuration Pre-Driver - Low Side
Output Current 5mA
Supply Current-Max (Isup) 0.4mA
Motor Type - AC, DC Brushless DC (BLDC)
Dimensions
Length 4.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
