AMT49413GEVATR
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Motor Drivers, Controllers
Description
Power MOSFET Tape & Reel (TR) SEATED HT-NOM General Purpose motor driver 45V 7mm -40C~105C TA
PDF
/
Buying Options
Total Price: USD $3.61
Unit Price: USD $3.608
≥1 USD $3.608
≥10 USD $3.23664
≥100 USD $3.059584
≥500 USD $2.651704
≥1000 USD $2.515744
≥3000 USD $2.257376
Inventory: 11761
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 0.9mm
Technical
Motor Type - AC, DC Brushless DC (BLDC)
Output Configuration Half Bridge (3)
Analog IC - Other Type BRUSHLESS DC MOTOR CONTROLLER
Interface Parallel, PWM
Supply Voltage-Min (Vsup) 7V
Supply Voltage-Max (Vsup) 45V
Function Controller - Commutation, Direction Management
JESD-30 Code S-XQCC-N48
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 5.5V~50V
Technology Power MOSFET
HTS Code 8542.39.00.01
Additional Feature SEATED HT-NOM
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
