UCC2973PWTR
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Lighting, Ballast Controllers
Description
IC FLUOR LAMP DRVR CTRLR 8TSSOP
PDF
/
Buying Options
Total Price: USD $4.59
Unit Price: USD $4.5866
≥1 USD $4.5866
≥10 USD $3.7639
≥100 USD $3.6461
≥500 USD $3.5283
≥1000 USD $3.4105
Inventory: 1576
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
ECCN Code EAR99
Type CCFL Controller
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Switching Regulator or Controllers
Technology BICMOS
Voltage - Supply 4.5V~20V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 12V
Terminal Pitch 0.65mm
Frequency 80kHz~160kHz
Base Part Number UCC2973
Pin Count 8
Input Voltage-Nom 12V
Power Supplies 12V
Operating Supply Current 7mA
Nominal Supply Current 1mA
Output Current 100mA
Min Input Voltage 4.5V
Control Mode CURRENT-MODE
Max Input Voltage 25V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration CURRENT FED PUSH-PULL
Dimming No
Dimensions
Height 1.2mm
Length 3mm
Width 4.4mm
Thickness 1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
