L6521
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Lighting, Ballast Controllers
Description
Electronic Ballast Controller 16V 8-Pin SO N Tube
PDF
/
Buying Options
Total Price: USD $374.54
Unit Price: USD $374.54415
≥1 USD $374.54415
Inventory: 306
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -25°C~85°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Type CFL/TL Controller
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Switching Regulator or Controllers
Voltage - Supply 10.5V~18.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 16V
Terminal Pitch 1.27mm
Frequency 46kHz~47.2kHz
Base Part Number L6521
Pin Count 8
Operating Supply Voltage 18.5V
Power Supplies 16V
Supply Voltage-Min (Vsup) 10.5V
Operating Supply Current 8mA
Dimming No
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
