HV809LG-G
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Lighting, Ballast Controllers
Description
Display Drivers & Controllers HVCMOS
PDF
/
Buying Options
Total Price: USD $2.27
Unit Price: USD $2.2704
≥1 USD $2.2704
≥10 USD $1.8832
≥100 USD $1.7072
Inventory: 3076
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height 1.5mm
Technical
Multiplexed Display Capability NO
Number of Segments 1
Dimming No
Operating Supply Current 400μA
Max Output Current 4mA
Base Part Number HV809
Time@Peak Reflow Temperature-Max (s) 40
Frequency 320Hz~480Hz 800Hz~1.2kHz
Terminal Pitch 1.27mm
Supply Voltage 10V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 50V~200V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Type EL Lamp Driver
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
Physical
Weight 142.994995mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 5 Weeks
