TPS92692PWPR
RoHS
RoHS compliant
RoHS compliantPackage 20-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tape & Reel (TR) TPS92692 Step-Down (Buck) Step-Up (Boost) Analog PWM led driver 6.5mm 14V 80kHz~800kHz -40C~125C TA
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.376
≥1 USD $2.376
≥10 USD $2.134
≥100 USD $2.013088
≥500 USD $1.715208
≥1000 USD $1.610506
≥3000 USD $1.409197
Inventory: 17484
Minimum: 1
-
+
Technical Details
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 20
ECCN Code EAR99
Type DC DC Controller
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Lighting, Signage
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 14V
Terminal Pitch 0.65mm
Frequency 80kHz~800kHz
Base Part Number TPS92692
Number of Outputs 1
Topology Step-Down (Buck), Step-Up (Boost)
Internal Switch(s) No
fmax-Min 0.002 MHz
Dimming Analog, PWM
Number of Segments 1
Voltage - Supply (Max) 65V
Voltage - Supply (Min) 4.5V
Multiplexed Display Capability NO
Dimensions
Height 1.2mm
Length 6.5mm
Width 4.4mm
Thickness 1mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-PowerTSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
Alternative Model
