TPS92550TZ/NOPB

Texas Instruments
RoHS
RoHS RoHS compliant
Package TO-PMOD-7, Power Module
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description Cut Tape (CT) TPS92550 Step-Down (Buck) PWM led driver 10.16mm 450mA 36V 14W
PDF
/
Buying Options
Total Price: USD $7.61
Unit Price: USD $7.612
≥1 USD $7.612
≥10 USD $6.87896
≥100 USD $6.559168
≥500 USD $5.695448
Inventory: 1176
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-PMOD-7, Power Module
Number of Pins 7

Technical

Operating Temperature -40°C~125°C TJ
Packaging Cut Tape (CT)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 7
ECCN Code EAR99
Type DC DC Regulator
Terminal Finish Matte Tin (Sn)
Applications Lighting
Subcategory Display Drivers
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 24V
Current Rating 450mA
Base Part Number TPS92550
Number of Outputs 1
Output Voltage 36V
Power Supplies 24V
Max Supply Voltage 36V
Min Supply Voltage 4.5V
Nominal Supply Current 2.7mA
Output Current 450mA
Max Supply Current 2.7mA
Quiescent Current 2.35mA
Topology Step-Down (Buck)
Min Input Voltage 4.5V
Max Input Voltage 36V
Output Characteristics CONSTANT-CURRENT
Input Characteristics STANDARD
Max Output Power 14W
Internal Switch(s) Yes
Dimming PWM
Number of Segments 10
Switching Frequency 400kHz
Multiplexed Display Capability NO

Dimensions

Height 4.8mm
Length 10.16mm
Width 9.85mm
Thickness 4.57mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
