TCA6507ZXUR
RoHS
RoHS compliant
RoHS compliantPackage 12-UFBGA
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tape & Reel (TR) TCA6507 I2C SMBus Surface Mount led driver 2mm 40mA 3.6V 100kHz 400kHz
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 1101
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 12-UFBGA
Surface Mount YES
Number of Pins 12
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Linear
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
HTS Code 8542.39.00.01
Subcategory Display Drivers
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Frequency 100kHz 400kHz
Base Part Number TCA6507
Pin Count 12
Number of Outputs 7
Power Supplies 1.8/3.3V
Max Supply Voltage 3.6V
Min Supply Voltage 1.65V
Supply Current-Max 0.04mA
Voltage - Output 5.5V
Output Characteristics OPEN-DRAIN
Input Characteristics STANDARD
Low Level Output Current 40mA
fmax-Min 23 MHz
Dimming I2C, SMBus
Number of Segments 7
Voltage - Supply (Max) 3.6V
Multiplexed Display Capability NO
Data Input Mode SERIAL
Dimensions
Height 610μm
Length 2mm
Width 2.5mm
Thickness 500μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
