LP8863ADCPRQ1
RoHS
RoHS compliant
RoHS compliantPackage 38-TFSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tape & Reel (TR) LP8863 Step-Up (Boost) PWM led driver 9.7mm 150mA 12V 300kHz~2.2MHz
PDF
/
Buying Options
Total Price: USD $3.94
Unit Price: USD $3.9424
≥1 USD $3.9424
≥10 USD $3.53672
≥100 USD $3.343648
≥500 USD $2.89784
≥1000 USD $2.749226
≥3000 USD $2.466886
Inventory: 621
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 38-TFSOP (0.173, 4.40mm Width) Exposed Pad
Surface Mount YES
Number of Pins 38
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 38
ECCN Code EAR99
Type DC DC Controller
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Automotive, Backlight
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 12V
Terminal Pitch 0.5mm
Frequency 300kHz~2.2MHz
Base Part Number LP8863
Number of Outputs 6
Topology Step-Up (Boost)
Current - Output / Channel 150mA
Internal Switch(s) No
fmax-Min 0.02 MHz
Dimming PWM
Supply Voltage1-Nom 3.3V
Number of Segments 30
Voltage - Supply (Max) 48V
Voltage - Supply (Min) 3V
Multiplexed Display Capability YES
Data Input Mode SERIAL
Dimensions
Height 1.2mm
Length 9.7mm
Width 4.4mm
Thickness 1.15mm
Compliance
RoHS Status ROHS3 Compliant
