LM3508TL
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Non-RoHS Compliant BALL BOTTOM SERIAL led driver 85C 850kHz 5.5V 0.675mm
PDF
/
Buying Options
Total Price: USD $1.32
Unit Price: USD $1.3167
≥1 USD $1.3167
≥10 USD $1.08015
≥100 USD $1.0469
≥500 USD $1.0127
≥1000 USD $0.97945
Inventory: 17008
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 0.675mm
Technical
Data Input Mode SERIAL
Multiplexed Display Capability NO
Number of Segments 4
Interface IC Type LED DISPLAY DRIVER
Frequency - Switching 850kHz
Min Supply Voltage 2.7V
Max Supply Voltage 5.5V
Temperature Grade OTHER
Qualification Status Not Qualified
Pin Count 9
Terminal Pitch 0.5mm
Supply Voltage 3.6V
Number of Functions 1
Terminal Form BALL
Terminal Position BOTTOM
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e1
Packaging Tape and Reel
Physical
Number of Pins 9
Mount Surface Mount
