LM2704MFX-ADJ/NOPB
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
ROHS3Compliant GULL WING DUAL VOLTAGE-MODE IC LED Driver -40C~85C TA 2.2V 550mA Switch 2.9mm
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
Inventory: 3031
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 2.9mm
Technical
Voltage - Supply (Max) 7V
Internal Switch(s) Yes
Current - Output / Channel 550mA Switch
Control Technique CONSTANT OFF TIME
Output Current-Max 0.62A
Control Mode VOLTAGE-MODE
Min Input Voltage 2.2V
Topology Step-Up (Boost)
Voltage - Output 20V
Input Voltage-Nom 2.2V
Output Type Adjustable
Output Voltage 20.5V
Efficiency 80 %
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 5
Base Part Number LM2704
Time@Peak Reflow Temperature-Max (s) 40
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Analog ICs
Applications Backlight
Terminal Finish Matte Tin (Sn)
Type DC DC Regulator
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
