HVLED805
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tube HVLED805 Flyback PWM led driver 10mm 1.7mA 23V 900mW
PDF
/
Buying Options
Total Price: USD $33.49
Unit Price: USD $33.4875
≥1 USD $33.4875
≥10 USD $27.47685
≥100 USD $26.61805
≥500 USD $25.7602
≥1000 USD $24.9014
Inventory: 1530
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
ECCN Code EAR99
Type AC DC Offline Switcher
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Display Drivers
Max Power Dissipation 900mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 14V
Frequency 166kHz
Base Part Number HVLED805
Pin Count 16
Number of Outputs 1
Max Supply Voltage 23V
Min Supply Voltage 11.5V
Power Dissipation 900mW
Max Supply Current 1.7mA
Topology Flyback
Min Input Voltage 11.5V
Max Input Voltage 23V
Internal Switch(s) Yes
Dimming PWM
Number of Segments 3
Switching Frequency 166kHz
Multiplexed Display Capability NO
Dimensions
Height 1.6mm
Length 10mm
Width 4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Alternative Model
