LC5225D
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm), 7 Leads
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
IC LED DRVR OFFL DIM 400MA 8DIP
PDF
/
Inventory: 1156
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Voltage - Supply (Min) 25V
Dimming PWM
Internal Switch(s) Yes
Current - Output / Channel 400mA
Output Current per Channel 400mA
Topology Step-Down (Buck), Step-Up (Boost)
Max Supply Voltage 400V
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Type AC DC Offline Switcher
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
Published 2012
Packaging Tube
Operating Temperature -40°C~105°C TA
Physical
Package / Case 8-DIP (0.300, 7.62mm), 7 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
