BD9421F-GE2
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.213, 5.40mm Width)
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Cut Tape (CT) Step-Down (Buck) Analog Surface Mount led driver 15mm 35V 150kHz -40C~85C TA
PDF
/
Buying Options
Total Price: USD $15.06
Unit Price: USD $15.06035
≥1 USD $15.06035
≥10 USD $12.3576
≥100 USD $11.97095
≥500 USD $11.58525
≥1000 USD $11.1986
Inventory: 1150
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.4mm
Length 15mm
Height Seated (Max) 2.01mm
Technical
Multiplexed Display Capability NO
Voltage - Supply (Min) 9V
Number of Segments 72
Dimming Analog
Internal Switch(s) Yes
Topology Step-Down (Buck)
Max Supply Voltage 35V
Number of Outputs 6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 150kHz
Terminal Pitch 1.27mm
Supply Voltage 24V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8542.39.00.01
Applications Backlight
Type DC DC Controller
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2015
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 24
Package / Case 24-SOIC (0.213, 5.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
