LM3432SQ/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 24-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
ROHS3Compliant Backlight Obsolete DC DC Regulator IC LED Driver -40C~125C TJ 80V 40mA
PDF
/
Buying Options
Total Price: USD $14.24
Unit Price: USD $14.23575
≥1 USD $14.23575
≥10 USD $11.6812
≥100 USD $11.31545
≥500 USD $10.95065
≥1000 USD $10.58585
Inventory: 7204
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - Supply (Min) 6V
Voltage - Supply (Max) 40V
Dimming Analog, PWM
Internal Switch(s) Yes
Current - Output / Channel 40mA
Topology Step-Up (Boost)
Voltage - Output 80V
Number of Outputs 6
Applications Backlight
Type DC DC Regulator
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Supplier Device Package 24-WQFN (4x5)
Package / Case 24-WFQFN Exposed Pad
Mounting Type Surface Mount
