LYT0006D
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width), 7 Leads
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tube Flyback SEPIC Step-Down (Buck) Step-Up (Boost) LYTSwitch?-0 Surface Mount led driver 280mA 308V 66kHz -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $1.66
Unit Price: USD $1.65965
≥1 USD $1.65965
≥10 USD $1.36135
≥100 USD $1.31955
≥500 USD $1.2768
≥1000 USD $1.23405
Inventory: 7805
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width), 7 Leads
Number of Pins 7
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
Published 2013
Series LYTSwitch?-0
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type AC DC Offline Switcher
Pin Count 5
Number of Outputs 1
Output Voltage 54V
Max Output Current 280mA
Output Current 280mA
Max Supply Current 226μA
Max Output Voltage 700V
Topology Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost)
Output Current per Channel 401mA
Min Output Voltage -300mV
Internal Switch(s) Yes
Switching Frequency 66kHz
Voltage - Supply (Max) 308VAC
Voltage - Supply (Min) 85VAC
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 308V
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
