NCV78702MW0R2G
RoHS
/
Package 24-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tape & Reel (TR) Boost PWM Automotive AEC-Q100 led driver 4mm 50mA 30V 10MHz
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
≥3000 USD $2.68565
Inventory: 13539
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 4mm
Length 4mm
Technical
Data Input Mode SERIAL
Voltage - Supply (Min) 5V
Voltage - Supply (Max) 30V
Number of Segments 1
Dimming PWM
Internal Switch(s) No
Current - Output / Channel 50mA
Topology Boost
Number of Outputs 1
JESD-30 Code S-PQCC-N24
Frequency 10MHz
Terminal Pitch 0.5mm
Number of Functions 1
Terminal Position QUAD
Applications Automotive
Terminal Finish Tin (Sn)
Type DC DC Controller
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Surface Mount YES
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 26 Weeks
