LV5235VZ-MPB-H
RoHS
/
Package 44-LSSOP (0.220, 5.60mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Lead Free RoHS Compliant Obsolete Linear IC LED Driver -25C~75C TA 1MHz 5.5V 100mA
PDF
/
Buying Options
Total Price: USD $3.13
Unit Price: USD $3.134182
≥1 USD $3.134182
≥10 USD $2.956777
≥100 USD $2.789412
≥500 USD $2.63152
≥1000 USD $2.482564
Inventory: 9233
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Voltage - Supply (Min) 4.5V
Dimming PWM
Internal Switch(s) Yes
Current - Output / Channel 100mA
Output Current per Channel 100mA
Voltage - Output 42V
Max Supply Voltage 5.5V
Number of Outputs 18
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 1MHz
Peak Reflow Temperature (Cel) NOT SPECIFIED
HTS Code 8542.39.00.01
Terminal Finish Tin/Bismuth (Sn/Bi)
Type Linear
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e6
Published 2013
Packaging Tube
Operating Temperature -25°C~75°C TA
Physical
Package / Case 44-LSSOP (0.220, 5.60mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
