CAT4104VP2-GT3

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 8-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description Tape & Reel (TR) CAT4104 PWM Surface Mount led driver 3mm 175mA 5.5V -40C~85C TA
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.0472
≥1 USD $1.0472
≥10 USD $0.9328
≥100 USD $0.88528
≥500 USD $0.679888
≥1000 USD $0.600794
≥3000 USD $0.569166
Inventory: 22679
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 13 Weeks
Lifecycle Status ACTIVE (Last Updated: 22 hours ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-WFDFN Exposed Pad
Number of Pins 8

Technical

Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Linear
Applications Automotive, Backlight, Lighting
Subcategory Display Drivers
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.5mm
Current Rating 175mA
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number CAT4104
Pin Count 8
Number of Outputs 4
Qualification Status Not Qualified
Power Supplies 5V
Max Supply Voltage 5.5V
Min Supply Voltage 3V
Output Current 700mA
Voltage - Output 25V
Min Input Voltage 3V
Max Input Voltage 5.5V
Halogen Free Halogen Free
Output Current per Channel 175mA
Internal Switch(s) Yes
High Level Output Current 700mA
Low Level Output Current 175mA
Dimming PWM
Number of Segments 4
Multiplexed Display Capability NO

Dimensions

Length 3mm
Width 2mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
