CAT4104V-GT3
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tape & Reel (TR) CAT4104 PWM Surface Mount led driver 5mm 700mA 5.5V -40C~85C TA
PDF
/
Buying Options
Total Price: USD $1.44
Unit Price: USD $1.4432
≥1 USD $1.4432
≥10 USD $1.28832
≥100 USD $1.222496
≥500 USD $0.938608
≥1000 USD $0.829488
≥3000 USD $0.78584
Inventory: 1250
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2009
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Linear
Applications Backlight, Lighting
Subcategory Display Drivers
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number CAT4104
Pin Count 8
Number of Outputs 4
Power Supplies 5V
Max Supply Voltage 5.5V
Min Supply Voltage 3V
Output Current 700mA
Max Supply Current 175mA
Voltage - Output 25V
Min Input Voltage 3V
Max Input Voltage 5.5V
Halogen Free Halogen Free
Output Current per Channel 175mA
Internal Switch(s) Yes
High Level Output Current 700mA
Low Level Output Current 175mA
Dimming PWM
Number of Segments 4
Multiplexed Display Capability NO
Dimensions
Height 1.5mm
Length 5mm
Width 4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
