CAT3648HV3-GT2

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 16-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description Tape & Reel (TR) CAT3648 Switched Capacitor (Charge Pump) Multi-Step led driver 3mm 30mA 6V 1MHz~1.3MHz
PDF
/
Buying Options
Total Price: USD $1.94
Unit Price: USD $1.9361
≥1 USD $1.9361
≥10 USD $1.5884
≥100 USD $1.539
≥500 USD $1.4896
≥1000 USD $1.43925
Inventory: 1196
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 3mm
Length 3mm
Height Seated (Max) 0.8mm

Technical

Data Input Mode SERIAL
Multiplexed Display Capability NO
Voltage - Supply (Min) 2.5V
Number of Segments 4
Dimming Multi-Step
Internal Switch(s) Yes
Output Current per Channel 25mA
Halogen Free Halogen Free
Topology Switched Capacitor (Charge Pump)
Voltage - Output 7V
Max Output Voltage 6V
Output Current 100mA
Min Supply Voltage 2.5V
Max Supply Voltage 5.5V
Number of Outputs 4
Pin Count 16
Base Part Number CAT3648
Time@Peak Reflow Temperature-Max (s) 40
Frequency 1MHz~1.3MHz
Current Rating 30mA
Terminal Pitch 0.5mm
Supply Voltage 3.6V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Subcategory Display Drivers
Applications Backlight
Type DC DC Regulator
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Number of Pins 16
Package / Case 16-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 2 Weeks
