HV9923N3-G
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Bulk HV9923 Step-Down (Buck) Triac led driver 453.59237mg 30mA 400V 740mW
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7744
≥1 USD $0.7744
Inventory: 616
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Display Mode SEGMENT
Multiplexed Display Capability NO
Voltage - Supply (Min) 20V
Number of Segments 1
Dimming Triac
Internal Switch(s) Yes
Max Output Power 740mW
Output Current per Channel 30mA
Max Input Voltage 400V
Min Input Voltage 20V
Topology Step-Down (Buck)
Max Supply Current 350μA
Output Current 30mA
Power Dissipation 740mW
Max Supply Voltage 400V
Power Supplies 7.5V
Qualification Status Not Qualified
Number of Outputs 1
Base Part Number HV9923
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Current Rating 30mA
Supply Voltage 7.5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Position BOTTOM
Max Power Dissipation 740mW
Subcategory Display Drivers
Applications Lighting
Terminal Finish Matte Tin (Sn) - annealed
Type AC DC Offline Switcher
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2011
Packaging Bulk
Operating Temperature -40°C~85°C TA
Physical
Weight 453.59237mg
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
