HV98100T-E/CH
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tape & Reel (TR) HV98100 Step-Down (Buck) Step-Up (Boost) Surface Mount led driver 2.9mm 12V -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $4.38
Unit Price: USD $4.38235
≥1 USD $4.38235
≥10 USD $3.59575
≥100 USD $3.48365
≥500 USD $3.3706
≥1000 USD $3.2585
Inventory: 19
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type Surface Mount
Package / Case SOT-23-6
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
Published 2017
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type AC DC Offline Switcher
Applications Lighting
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 12V
Terminal Pitch 0.95mm
Base Part Number HV98100
JESD-30 Code R-PDSO-G6
Number of Outputs 1
Topology Step-Down (Buck), Step-Up (Boost)
Internal Switch(s) No
Number of Segments 2
Voltage - Supply (Max) 16V
Voltage - Supply (Min) 8V
Multiplexed Display Capability NO
Dimensions
Length 2.9mm
Compliance
RoHS Status ROHS3 Compliant
