MAX6946CAWE+T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
IC LED DRIVER LINEAR 20MA 16WLP
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.3148
≥1 USD $1.3148
≥10 USD $1.07825
≥100 USD $1.045
≥500 USD $1.0108
≥1000 USD $0.97755
Inventory: 79607
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Number of Pins 16
Technical
Packaging Strip
Published 2008
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Max Power Dissipation 1.066W
Frequency 400kHz
Number of Outputs 10
Output Voltage 7V
Operating Supply Voltage 3.6V
Max Supply Voltage 3.63V
Power Dissipation 1.176W
Max Supply Current 60μA
Output Current per Channel 20mA
Low Level Output Current 21.12mA
Number of Segments 3
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
