MAX16815ATT+
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
RoHS Compliant DUAL BICMOS AUTOMOTIVE led driver 125C 1.4545W 40V 3mm
PDF
/
Inventory: 7477
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Multiplexed Display Capability NO
Number of Segments 1
Interface IC Type LED DISPLAY DRIVER
Power Dissipation-Max 1.4545W
Temperature Grade AUTOMOTIVE
Power Supplies 12V
Operating Supply Voltage 40V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 125°C
JESD-30 Code S-XDSO-N6
Pin Count 6
Terminal Pitch 0.95mm
Supply Voltage 12V
Number of Functions 1
Terminal Position DUAL
Technology BICMOS
Subcategory Display Drivers
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
Physical
Surface Mount YES
