LT3796HFE-1
RoHS
/
Package 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Non-RoHS Compliant GULL WING DUAL CURRENT-MODE IC LED Driver -40C~150C TJ 100kHz~1MHz 6V 10A
PDF
/
Inventory: 1171
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 4.4mm
Length 9.7mm
Technical
Voltage - Supply (Min) 6V
Voltage - Supply (Max) 100V
Dimming Analog, PWM
Internal Switch(s) No
Current - Output / Channel 10A
Switcher Configuration SINGLE
Control Technique PULSE WIDTH MODULATION
Control Mode CURRENT-MODE
Topology SEPIC, Step-Down (Buck), Step-Up (Boost)
Input Voltage (Min) 6V
Input Voltage-Nom 24V
Output Voltage 7.7V
Number of Outputs 1
JESD-30 Code R-PDSO-G28
Pin Count 28
Frequency 100kHz~1MHz
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Matte Tin (Sn)
Type DC DC Controller
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series True Color PWM?
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Surface Mount YES
Package / Case 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
