LT3795HFE
RoHS
/
Package 28-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tube Analog PWM Surface Mount EAR99 led driver 9.7mm 10A 24V 100kHz~1MHz
PDF
/
Buying Options
Total Price: USD $11.19
Unit Price: USD $11.190252
≥1 USD $11.190252
≥10 USD $10.556838
≥100 USD $9.95928
≥500 USD $9.395555
≥1000 USD $8.863729
Inventory: 1289
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 4.4mm
Length 9.7mm
Technical
Multiplexed Display Capability NO
Voltage - Supply (Min) 4.5V
Voltage - Supply (Max) 110V
Number of Segments 2
Dimming Analog, PWM
Internal Switch(s) No
Current - Output / Channel 10A
Number of Outputs 1
JESD-30 Code R-PDSO-G28
Pin Count 28
Frequency 100kHz~1MHz
Terminal Pitch 0.65mm
Supply Voltage 24V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Matte Tin (Sn)
Type DC DC Controller
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Surface Mount YES
Package / Case 28-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
