LT3598IUF#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 24-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
ROHS3Compliant NO LEAD QUAD Not Qualified IC LED Driver -40C~125C TJ 200kHz~2.5MHz 30V 30mA
PDF
/
Buying Options
Total Price: USD $8.61
Unit Price: USD $8.6064
≥1 USD $8.6064
≥10 USD $7.77744
≥100 USD $7.415584
≥500 USD $6.43896
≥1000 USD $6.149616
≥3000 USD $5.60699
Inventory: 2125
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 0.8mm
Technical
Multiplexed Display Capability NO
Voltage - Supply (Min) 3V
Number of Segments 60
Dimming Analog, PWM
Low Level Output Current 2mA
Internal Switch(s) Yes
Current - Output / Channel 30mA
Min Input Voltage 3.2V
Topology Step-Up (Boost)
Voltage - Output 44V
Min Supply Voltage 3.2V
Max Supply Voltage 30V
Power Supplies 5V
Qualification Status Not Qualified
Number of Outputs 6
Pin Count 24
Base Part Number LT3598
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 200kHz~2.5MHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 250
Terminal Form NO LEAD
Terminal Position QUAD
Technology BIPOLAR
Subcategory Display Drivers
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Type DC DC Regulator
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series True Color PWM?
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-WFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 16 Weeks
