LT3598EFE
RoHS
/
Package 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Non-RoHS Compliant GULL WING DUAL Not Qualified IC LED Driver -40C~125C TJ 200kHz~2.5MHz 5V 30mA
PDF
/
Buying Options
Total Price: USD $5.19
Unit Price: USD $5.193217
≥1 USD $5.193217
≥10 USD $4.899259
≥100 USD $4.621945
≥500 USD $4.360325
≥1000 USD $4.113511
Inventory: 3457
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
Series True Color PWM?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Type DC DC Regulator
Terminal Finish Matte Tin (Sn)
Applications Automotive
HTS Code 8542.39.00.01
Subcategory Display Drivers
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Frequency 200kHz~2.5MHz
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 24
JESD-30 Code R-PDSO-G24
Number of Outputs 6
Qualification Status Not Qualified
Power Supplies 5V
Voltage - Output 44V
Topology Step-Up (Boost)
Current - Output / Channel 30mA
Internal Switch(s) Yes
Dimming Analog, PWM
Number of Segments 60
Voltage - Supply (Max) 30V
Voltage - Supply (Min) 3V
Multiplexed Display Capability NO
Dimensions
Height Seated (Max) 1.2mm
Length 7.8mm
Width 4.4mm
Compliance
RoHS Status Non-RoHS Compliant
