LT3597IUHG#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 52-WFQFN, 39 Leads, Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
ROHS3Compliant NO LEAD QUAD Not Qualified IC LED Driver -40C~125C TJ 200kHz~1MHz 24V 100mA
PDF
/
Buying Options
Total Price: USD $6.42
Unit Price: USD $6.422707
≥1 USD $6.422707
≥200 USD $2.48532
≥500 USD $2.398668
≥1000 USD $2.355343
Inventory: 961
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 8mm
Height Seated (Max) 0.8mm
Technical
Multiplexed Display Capability NO
Voltage - Supply (Min) 6V
Voltage - Supply (Max) 55V
Number of Segments 10
Dimming PWM
Internal Switch(s) Yes
Current - Output / Channel 100mA
Topology Step-Down (Buck)
Power Supplies 24V
Qualification Status Not Qualified
Number of Outputs 3
Pin Count 52
Base Part Number LT3597
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 200kHz~1MHz
Terminal Pitch 0.4mm
Supply Voltage 24V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Technology BIPOLAR
Subcategory Display Drivers
Applications Backlight
Terminal Finish Matte Tin (Sn)
Type DC DC Regulator
ECCN Code EAR99
Number of Terminations 39
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case 52-WFQFN, 39 Leads, Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
