LT3519IMS-2#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 16-TFSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
ROHS3Compliant GULL WING DUAL Not Qualified IC LED Driver -40C~125C TJ 2.2MHz 12V 750mA Switch
PDF
/
Buying Options
Total Price: USD $65.68
Unit Price: USD $65.6811
≥1 USD $65.6811
≥10 USD $53.89255
≥100 USD $52.2082
≥500 USD $50.5248
≥1000 USD $48.84045
Inventory: 1113
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 4.039mm
Technical
Multiplexed Display Capability NO
Voltage - Supply (Min) 3V
Voltage - Supply (Max) 30V
Number of Segments 1
Dimming Analog, PWM
Internal Switch(s) Yes
Current - Output / Channel 750mA Switch
Topology SEPIC, Step-Down (Buck), Step-Up (Boost)
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 16
Base Part Number LT3519
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 2.2MHz
Terminal Pitch 0.5mm
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Display Drivers
Applications Lighting
Terminal Finish Matte Tin (Sn)
Type DC DC Regulator
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case 16-TFSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
