THL3502
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
ROHS3Compliant Backlight Signage Active Power Switch led driver -40C~85C TA 10MHz 5.5V 100mA
PDF
/
Buying Options
Total Price: USD $76.26
Unit Price: USD $76.2603
≥1 USD $76.2603
≥10 USD $73.8777
≥100 USD $71.49415
≥500 USD $69.11155
≥1000 USD $61.96185
Inventory: 1806
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - Supply (Min) 3V
Voltage - Supply (Max) 5.5V
Internal Switch(s) Yes
Current - Output / Channel 100mA
Output Current per Channel 100mA
Voltage - Output 35V
Max Supply Voltage 5.5V
Number of Outputs 24
Frequency 10MHz
Applications Backlight, Signage
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type Power Switch
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series THine?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Supplier Device Package 48-QFN (7x7)
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
