A8518KLPTR-T-1
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tape & Reel (TR) Step-Up (Boost) Analog PWM Automotive AEC-Q100 led driver 5mm 200mA 16V 2.15MHz
PDF
/
Buying Options
Total Price: USD $1.95
Unit Price: USD $1.950222
≥1 USD $1.950222
≥10 USD $1.83983
≥100 USD $1.735689
≥500 USD $1.637445
≥1000 USD $1.544753
Inventory: 1559
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 5mm
Technical
Multiplexed Display Capability NO
Voltage - Supply (Min) 4.5V
Voltage - Supply (Max) 40V
Number of Segments 4
Dimming Analog, PWM
fmax-Min 1 MHz
Internal Switch(s) Yes
Current - Output / Channel 200mA
Topology Step-Up (Boost)
Number of Outputs 2
JESD-30 Code R-PDSO-G16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 2.15MHz
Terminal Pitch 0.65mm
Supply Voltage 16V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Applications Automotive, Backlight
Type DC DC Regulator
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q100
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
