MAX3656ETG-T
RoHS
RoHS compliant
RoHS compliantPackage 24-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Laser Drivers
Description
Obsolete Tape & Reel (TR) Laser Diode Driver (Fiber Optic) ROHS3Compliant IC Laser Driver 2.5Gbps 1.805W 3.3V 4mm
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6055
≥1 USD $1.6055
≥10 USD $1.31765
≥100 USD $1.2768
≥500 USD $1.235
≥1000 USD $1.19415
Inventory: 1093
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 0.8mm
Technical
Current - Bias 70mA
Current - Modulation 85mA
Data Rate 2.5Gbps
Operating Supply Current 40mA
Number of Channels 1
Operating Supply Voltage 3.3V
Pin Count 24
Base Part Number MAX3656
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Technology BIPOLAR
Max Power Dissipation 1.805W
Subcategory Display Drivers
Type Laser Diode Driver (Fiber Optic)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 24
Package / Case 24-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
