MAX3296CTI+
RoHS
RoHS compliant
RoHS compliantPackage 28-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Laser Drivers
Description
Not Qualified Obsolete Tube Laser Diode Driver (Fiber Optic) IC Laser Driver 2.5Gbps 5.5V 5mm 30mA
PDF
/
Buying Options
Total Price: USD $5.98
Unit Price: USD $5.984
≥1 USD $5.984
Inventory: 9117
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Current - Modulation 30mA
Data Rate 2.5Gbps
Operating Supply Current 52mA
Number of Channels 1
Power Supplies 3.3/5V
Operating Supply Voltage 5.5V
Qualification Status Not Qualified
JESD-30 Code S-XQCC-N28
Pin Count 28
Base Part Number MAX3296
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 3V~5.5V
Technology BIPOLAR
Subcategory Display Drivers
Terminal Finish Matte Tin (Sn)
Type Laser Diode Driver (Fiber Optic)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2005
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Package / Case 28-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
