DS1864T+
RoHS
RoHS compliant
RoHS compliantPackage 28-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Laser Drivers
Description
DS1864 EAR99 2006 QUAD laser driver -40C~95C 3mA 5mm 3/5V
PDF
/
Buying Options
Total Price: USD $4.77
Unit Price: USD $4.769
≥1 USD $4.769
≥10 USD $3.91305
≥100 USD $3.7905
≥500 USD $3.6689
≥1000 USD $3.54635
Inventory: 1370
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Current - Supply 3mA
Number of Channels 1
Power Supplies 3/5V
Qualification Status Not Qualified
JESD-30 Code S-XQCC-N28
Pin Count 28
Base Part Number DS1864
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.97V~5.5V
Subcategory Display Drivers
Terminal Finish Matte Tin (Sn)
Type Laser Diode Controller (Fiber Optic)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tube
Operating Temperature -40°C~95°C
Physical
Surface Mount YES
Package / Case 28-WFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
