TPS2022PE4
RoHS
/
Package DIP
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Lead Free INDUSTRIAL MOS RoHS Compliant hot swap controller 40000μs 85C 5.5V 1A
PDF
/
Inventory: 9511
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 7.62mm
Technical
Output Current Flow Direction SOURCE
Built-in Protections TRANSIENT; OVER CURRENT; THERMAL; UNDER VOLTAGE
Turn Off Time 40000 μs
Output Peak Current Limit-Nom 1.5A
Turn On Time 20000 μs
Driver Number of Bits 1
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Nominal Input Voltage 5.5V
Output Current-Max 1A
Max Supply Voltage 5.5V
Temperature Grade INDUSTRIAL
Power Supplies 3/5V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology MOS
Subcategory Peripheral Drivers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 8
Physical
Weight 440.409842mg
Number of Pins 8
Package / Case DIP
Mount Through Hole
