TPS2020DG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Nickel/Palladium/Gold (Ni/Pd/Au) EAR99 TRANSIENT; OVER CURRENT; THERMAL; UNDER VOLTAGE SOURCE hot swap controller 4.9mm 0.2A 5.5V 85C
PDF
/
Inventory: 9083
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Output Current Flow Direction SOURCE
Built-in Protections TRANSIENT; OVER CURRENT; THERMAL; UNDER VOLTAGE
Turn Off Time 40000 μs
Output Peak Current Limit-Nom 0.3A
Turn On Time 20000 μs
Driver Number of Bits 1
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Nominal Input Voltage 5.5V
Max Input Voltage 5.5V
Output Current-Max 0.2A
Min Input Voltage 2.7V
Min Supply Voltage 2.7V
Max Supply Voltage 5.5V
Temperature Grade INDUSTRIAL
Power Supplies 3/5V
Number of Outputs 1
Pin Count 8
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology MOS
Subcategory Peripheral Drivers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Physical
Weight 72.603129mg
Number of Pins 8
Surface Mount YES
Package / Case SOIC
