ISL6142CB
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Obsolete Surface Mount GULL WING Non-RoHS Compliant Hot Swap Controller 0C~70C 20V~80V 2.6mA 8.65mm
PDF
/
Buying Options
Total Price: USD $2.29
Unit Price: USD $2.288
≥1 USD $2.288
Inventory: 1075
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Technical
Feature Pins CT, DIS, DRAIN, /FAULT, OV, /PWRGD, UV
Programmable Features Current Limit, Fault Timeout, OVP, UVLO
Internal Switch(s) No
Current - Supply 2.6mA
Adjustable Threshold YES
Number of Channels 1
Supply Voltage-Min (Vsup) 20V
Supply Voltage-Max (Vsup) 80V
Pin Count 14
Supply Voltage 48V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 20V~80V
Applications -48V, VoIP
Terminal Finish TIN LEAD
Type Hot Swap Controller
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Auto Retry
JESD-609 Code e0
Series IntelliTrip?
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
