ISL6112IRZA
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Obsolete Surface Mount NO LEAD ROHS3Compliant Hot Plug Controller -40C~85C 3.3V 12V 900muA 7mm
PDF
/
Buying Options
Total Price: USD $7.26
Unit Price: USD $7.26
≥1 USD $7.26
Inventory: 2230
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1mm
Technical
Feature Pins AUXENA, AUXENB, CFILTERA, CFILTERB, ONA, ONB, /PWRGDA, /PWRGDB, FAULTA, FAULTB, /FORCE_ONA, /FORCE_ONB
Programmable Features Current Limit, Fault Timeout
Internal Switch(s) Both
Current - Supply 900μA
Adjustable Threshold YES
Number of Channels 6
Supply Voltage-Min (Vsup) 2.97V
JESD-30 Code S-PQCC-N48
Base Part Number ISL6112
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 3.3V 12V
Additional Feature ITS ALSO OPERATE FROM 12V SUPPLY
Applications PCI Express?
Type Hot Plug Controller
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Feature Thermal Limit, UVLO
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount
