MAX5936AAESA+T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Obsolete Surface Mount BICMOS GULL WING Hot Swap Controller -40C~85C -80V~-10V 950muA 4.9mm
PDF
/
Inventory: 9470
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series Load Probe?
JESD-609 Code e3
Feature Auto Retry, Fault Timeout
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Hot Swap Controller
Terminal Finish Matte Tin (Sn)
Applications -48V
Subcategory Power Management Circuits
Technology BICMOS
Voltage - Supply -80V~-10V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number MAX5936
Pin Count 8
Number of Channels 1
Adjustable Threshold NO
Current - Supply 950μA
Internal Switch(s) No
Programmable Features Slew Rate, UVLO
Feature Pins LP, /PGOOD, STEP_MON, UVLO
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
