MAX5916AUUI+
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Obsolete Surface Mount BICMOS GULL WING Hot Swap Controller 0C~85C 10.8V~13.2V 205mA 1A 9.7mm
PDF
/
Inventory: 8777
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 9.7mm
Height Seated (Max) 1.1mm
Technical
Feature Pins AUXONA, AUXONB, ONA, ONB, PGOODA, PGOODB
Programmable Features Circuit Breaker, Current Limit
Internal Switch(s) Both
Neg Supply Voltage-Nom (Vsup) -12V
Current - Supply 2.5mA
Adjustable Threshold YES
Current - Output (Max) 205mA 1A
Number of Channels 5
Supply Voltage-Min (Vsup) 10.8V
Power Supplies +-12V
Supply Voltage-Max (Vsup) 13.2V
Qualification Status Not Qualified
Pin Count 28
Base Part Number MAX5916
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 10.8V~13.2V
Technology BICMOS
Subcategory Power Management Circuits
Applications PCI
Terminal Finish Matte Tin (Sn)
Type Hot Swap Controller
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Auto Retry, Fault Timeout, Thermal Limit, UVLO
JESD-609 Code e3
Packaging Tube
Operating Temperature 0°C~85°C
Physical
Number of Pins 28
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
